AMS HADRONIC TOMOGRAPHY

September 29th, 2012

Operating in the International Space Station since May 2011, AMS is performing very accurate measurements of cosmic ray (e.g. Proton and Helium nuclei) with unprecedent sensitivity.

This picture represents a “tomographic” reconstruction of the AMS top-of-instrument material obtained using the Proton-to-Helium flux ratio.
Tiny changes of the interaction probabilities of these nuclei with different materials are used to trace the material inhomogenities. Detector elements such as screws, electronics boards, and mechanical interfaces are clearly recognizable.
